Video/Audio Input |
---|
|
Video Compression: | | | H.264 |
|
Analog Video Input: | | | 16-ch, BNC(1.0Vp-p, 75?), PAL/NTSC adaptive |
|
IP Video Input: | | | Up to 32-ch |
|
Composite Video Input: | | | Up to 32-ch (Analog video + IP video ) |
|
Audio Compression: | | | OggVorbis |
|
Audio Input: | | | 16-ch, Audio 1-4: RCA (2.0Vp-p, 1 k?), Audio 5-16 B26 onnector |
|
Two-way Audio: | | | 1-ch, RCA (2.0 Vp-p, 1 K?) (Using audio input) |
Video/Audio Output |
---|
|
CVBS Output: | | | 5-ch (1 Main output + 4 Spot outputs) BNC (1.0 Vp-p, 75 ?), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
|
HDMI Output: | | | 1920 × 1080 / 60 Hz (1080P), 1920 × 1080 / 50 Hz (1080P), 1600 × 1200 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
|
VGA Output: | | | 1920 × 1080 / 60 Hz (1080P), 1600 × 1200 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
|
Playback Resolution: | | | 5MP/3MP/1080p/UXGA/720P/WD1/4CIF/VGA/DCIF/2CIF/CIF/QCIF |
|
Recording Resolution: | | | Main stream: 4CIF / 2CIF / CIF / QCIF Sub-stream: CIF / QCIF |
|
Frame Rate: | | | Main stream: 25 fps (P) / 30 fps (N) Sub-stream: 25 fps (P) / 30 fps (N) |
|
Video Bit Rate: | | | 32 Kbps ~ 8 Mbps |
|
Audio Output: | | | 2-ch, RCA (2.0 Vp-p, 1 K?) |
|
Audio Bit Rate: | | | 16kbps |
|
Synchronous Playback: | | | 16-ch |
|
Dual Stream: | | | Support |
Hard Disk Driver |
---|
|
Interface Type: | | | 8 SATA interfaces for 4 HDDs + 1 DVD-R/W (default), or 8HDDs; 1 eSATA interface |
|
Capacity: | | | Up to 4 TB capacity for each disk |
Disk Array |
---|
|
Array Type: | | | RAID 0, RAID 1, RAID 5, RAID 10 |
|
Number of Array: | | | 8 |
|
Number of Virtual Dsk: | | | 8 |
External Interface |
---|
|
Network Interface: | | | 2; 10M/100M/1000M self-adaptive Ethernet interface |
|
Serial Interface: | | | RS-232, RS-485, Keyboard |
|
USB Interface: | | | 2, USB2.0 |
|
Alarm in/out: | | | 16 / 4 |
General |
---|
|
Power Supply: | | | 100~240VAC, 6.3A, 50~60Hz |
|
Consumption: | | | Max. 45W |
|
Working Temperature: | | | -10°C~+55°C(14°F~131°F) |
|
Working Humidity: | | | 10%~90% |
|
Chassis: | | | 19-inch rack-mounted 2U chassis |
|
Dimensions: | | | 445 × 470 × 90 mm |
|
Weight(Without HDD): | | | Approx. 8 kg / 17.6 lb (without hard disk or DVD-R/W) |
